PRESSURE REGULATORS 3/4 FNPT Adjustable Pressure Regulator 12-35psi At 2-22gpm – DIG 18-008

Adjustable Pressure Regulators

Direct acting adjustable pressure regulator designed where accurate and reliable control of line pressure is needed. Adjust pressure between 28 to 60 PSI . Maximum incoming pressure 125 PSI .

Features

• Adjustable with a single screw
• Rolling diaphragm keeps the spring assembly free of debris
• Reliable control regardless of fluctuations in upstream pressure or flow

Specifications

• Flow rates: .2-22 GPM (.045-5 m3/h)
• Pressure range: 12-60 PSI (.8-4 BAR)
• Max. working pressure: 125 PSI (8.6 BAR)
• Weight: .75 lb (.34 kg)
• 3/4″ FNPT
• Materials:
  • Body and actuator: plastic
  • Rolling diaphragm: nylon reinforced neoprene
  • Spring: stainless steel 304

Dimensions

• 4″ H x 3.44″ W (10 cm H x 19 cm W)
