DIG ML50 – Raised Bed Drip Irrigation Kit (10 Plant Rows)

The ML 50 Raised Bed Drip Kit is specially designed for planter boxes and vegetable garden layouts, offering a quick and simple solution for watering planter boxes or vegetables planted in rows. The kit has 50’ of ¼” drip line with pre-inserted inline drip emitters every 9” (total of 66 drip emitters) for installing a drip irrigation system with up to ten 5’ long rows. The pre inserted emitter flow rates are .52 GPH @ 15 PSI, and .65 GPH @ 25 PSI. The kit also contains 50′ of premium grade 1/2″ drip tubing with .600″ ID x .700″ OD manufactured from low-density polyethylene resin. The kit can be expanded to cover more than 700 SF by connecting up to five kits together or extending the system using additional ½” drip tubing as the main supply line along with ¼” drip line. The kit includes all the parts necessary to start a system from a faucet or garden hose.



Specifications:

• Operating pressure: 10 to 25 PSI (25 PSI pressure regulator included)

• Drip line flow rates: .52 GPH per outlet at 15 PSI and .65 GPH per outlet @ 25 PSI

• Drip line length: 50 feet

• Drip line drip emitter spacing: 9 inches

• Drip tubing size and length: ½ inch of 50 feet with .600 ID x .700 OD

• Drip line size and length: 1/4 inch of 50 feet with .170 ID x .270 OD

•Used with .700 OD (black) compression fittings

•Drip line color: black

• Total flow rate for this kit: 43.3 GPH (.72 GPM @ 25 PSI)

• Covers up to 100 square feet

• Manufacturer’s warranty: three year limited warranty

• Material: protected for extra resistance to the damaging effects of ultraviolet rays



Features:

• Applies water at a low application rate leading to less surface evaporation.

• Available with 360° micro sprinklers, inserts for 90°, 180° and strip patterns .

• The large diameter micro sprinkler has uniform water distribution.

• Offers flexibility in irrigation frequency and application rate, minimizing runoff.

• Designed for new and existing landscapes, including slopes and oblong areas.

• Outstanding crack resistance, UV protected.



Contents:

1 A015 D45 3/4 inch FHT x 3/4 Inch MHT backflow preventer

1 A013 D46 3/4 inch FHT 25 PSI preset pressure regulator

1 LF003 C34 3/4 inch FHT x .700 O.D. swivel adapter with screen washer

1 T004 B35 50’ coil of ½ inch drip tubing with .700 OD

1 LF001 C33 1/2 inch .700 OD compression coupling

3 LF005 C35 1/2 inch .700 OD compression tee

8 LF007 C36 1/2 inch .700 OD compression elbow

1 T051-NS50 SH109 50′ of 1/4 inch, .5 GPH @ 15 PSI drip line with 9 inch spacing

4 S030 R62B 6″ inch heavy duty hold down plastic stake for ½ inch drip tubing

10 S040 P31B 5″ inch heavy duty hold down plastic stake for ¼ inch drip line

15 SF001 H80A 1/4 inch barbed connector

5 A019 D44 hole punch

4 A006 F68B figure “8” hose end

5 SF007 G79B goof plugs strip of 10

1  26-023 instruction manual
